Vehicle Platform: Tiago,Tigor & Osprey
ECU Name: Hella Body Control Module (BCM)
DTC Troubleshooting Data
Version: 2.0
Date: 22-10-2018
Author: Parag K
Page: 680 of 737
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
B1324 – 09 : Window winding switch implausible-
Component Failure
Start
Connect the Diagnostic Tool and check for DTCs
Is DTC B1324 – 09
present?
STOP
Check DTC present is Current or history
Yes
History?
Yes
Is DTC B1324 –
09 present?
C
Yes
C
Any fault observed ?
Correct the
fault
Check continuity between BCM
connector pin
[C1-16]
and BCM
ground
[C1-3]
.
Disconnect vehicle battery connection.
(Please follow safety guidelines)
Check BCM and switch ( window) connectors
for terminal backout
1. Clear the DTC from memory.
2. Turn the IGN to OFF.
3. Start the IGN.
4. Check for DTCs.
No
Is continuity found ?
Replace
switch
Remove BCM side wiring harness Connector and Perform visual check
of connectors for pins bentor damaged etc
Is connector faulty?
BCM ECU faulty
Replace BCM ECU
No
Yes
No
Yes
No
Yes
No
No
Replace
Connector
