HARRIER BOOK 2

Vehicle Platform: Tiago,Tigor & Osprey

ECU Name: Hella Body Control Module (BCM)

DTC Troubleshooting Data

Version: 2.0

Date: 22-10-2018

Author: Parag K

Page: 507 of 737

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

DTC’s confirmation:-

After rectification, ensure the following points by using TML diagnostic tool before handing over to customer.

a) Run Input Switch Test routine, operate switches manually and check, DTC B220C – 11 is not returned with the

Routine results.

Circuit Schematic Diagram:-

Note:

For detailed information please refer latest BCM wiring harness schematic.

Component Location & Image:-

Connector Location:
