U100E - 11: Crank Power mode Input - Circuit Short to Ground
Overview:
ISO Code (DTC Code)
U100E - 11
Customer Symptom
Head lamps will operate during cranking.
Fault Effects (On Vehicle)
Head lamps will operate when in this power mode.
Lamp Status (If Any)
NA
Fault Detection Condition
This fault will be logged after the input switch test routine
execution. User has to operate the switch manually during
routine. If short to ground fault is detected for ignition power
mode input switch then this DTC code will be returned with
the Routine results.
Normal Operating Condition
There should not be any fault returned by routine.
Probable Trouble Area
1. BCM connector wired wrong
2. Cockpit wiring harness short to ground
3. switch damaged
Healing Condition
1. Ignition OFF
ON
2. Clear DTC Command
Component Details:
Crank Power mode Input switch is part of Ignition switch and interfaced to the BCM. If the Crank Power mode Input switch
is activated and engine will run successfully. If user put the ignition switch to Crank power mode input position, and engine
will run successfully.
Crank Power mode Input switch is active high.
Preliminary Checks:
1. Check Battery Voltage (9V-16V)
2. Check ECU pins for oxidation, bending & damage.
Trouble Shooting:-
