U1010 - 11: Key In Signal - Circuit Short to Ground
Overview:
ISO Code (DTC Code)
U1010 - 11
Customer Symptom
RKE Lock will operate when in this power mode
Fault Effects (On Vehicle)
RKE Lock will operate when in this power mode
Lamp Status (If Any)
NA
Fault Detection Condition
This fault will be logged after the input switch test routine
execution. User has to operate the switch manually during
routine. If short to ground fault is detected for ignition power
mode input switch then this DTC code will be returned with
the Routine results.
Normal Operating Condition
There should not be any fault returned by routine.
Probable Trouble Area
1. BCM connector wired wrong
2. Cockpit wiring harness short to ground
3. sensor damaged
Healing Condition
1. Ignition OFF
ON
2. Clear DTC Command
Component Details:
Key In input switch is part of Ignition switch and interfaced to the BCM. If the Key In input switch is activated and RKE
Lock functionality will not work. If user put the ignition switch to Key In power mode input position, RKE Lock functionality
will not work.
Key In input switch is active high.
Preliminary Checks:
1. Check Battery Voltage (9V-16V)
2. Check ECU pins for oxidation, bending & damage.
Trouble Shooting:-
