B224C – 1D: Right Turn Indicator – Circuit Current out of range
Overview:
ISO Code
B224C – 1D
Customer Symptom
Either Front Right Or Rear Right Turn Indicator bulb is OFF.
Other Lamp and Telltale flashes with Double frequency.
Fault Effects (On Vehicle)
Either Front Right Or Rear Right Turn Indicator bulb is OFF.
Lamp Status (If Any)
Either Front Right Or Rear Right Turn Indicator bulb Always
OFF
Fault Detection Condition
BCM log this fault when Either Front right Or Rear right Turn
Indicator bulb is Open Circuit.
Normal Operating Condition
Turn Indicator lamp comes ON when turn indicator switch is
activated.
Probable Trouble Area
1. BCM connector Fault
2. right Turn Indicator Lamp bulb blown /lamp damaged
3. BCM ECU fault.
Healing Condition
1. Ignition OFF
ON
2. Clear DTC Command
Component Details:
Right Turn Indicator lamps are located at right front, right rear and right side of the vehicle. Turn Indicator lamp
comes ON when turn indicator switch is activated.
Preliminary Checks:
1. Check Battery Voltage (12.5 V & above)
2. Check ECU pins for oxidation, bending & damage.
Trouble Shooting:-
