B224A – 11: Right Stop Lamp Circuit – Short to Ground
Overview:
ISO Code
B224A - 11
Customer Symptom
1. Right stop Lamps always OFF.
2. Brake lamp malfunction message on Instrument
Cluster
Fault Effects (On Vehicle)
Right Stop Lamps always OFF.
Lamp Status (If Any)
Always OFF
Fault Detection Condition
BCM log this fault when Right Stop lamp output is short to
ground.
Normal Operating Condition
Brake comes ON when brake is pressed.
Probable Trouble Area
1. BCM connector Fault
2. Right Stop lamp output wire Short to ground
3. Lamp damaged
4. BCM ECU fault
5. Right Stop lamp mating connector fault
Healing Condition
1. Ignition OFF
ON
2. Clear DTC Command
Component Details:
Right Stop lamps are located at right rear side of vehicle. Brake comes ON when brake is pressed.
Preliminary Checks:
1. Check Battery Voltage (12.5 V & above)
2. Check ECU pins for oxidation, bending & damage.
Trouble Shooting:-
