TML HARRIER Infotainment DTC Troubleshooting guide
Version: 0.3 Draft
Date: 17-Aug-18
Author:
Vijaya Bhaskar
B/Pritam Bansod
Page: 10 of 109
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
DTC’s confirmation:
Once DTC is rectified, on turning ON Radio in infotainment system, confirm that radio is playing as per the set
frequency.
Circuit Schematic Diagram:-
Component location & Image:-
Silver Box connector Location
Silver Box AM/FM
Antenna Connector
