U0028-13: Vehicle Communication Bus A - open circuit
Overview:
ISO Code
U0028-13
Customer Symptom
No visual indication
Fault Effects (On Vehicle)
Interfacing functions with Body Control Module, HVAC
Control Module and Instrument Panel Cluster Module will not
work.
Lamp Status (If Any)
NA
Fault Detection Condition
1. Open circuit of the CAN_H ( connector C1 pin no.2)
and/or CAN_L(connector C1 pin no.5)
Normal Operating Condition
ECU communicates properly with TML diagnostic Tool.
Probable Trouble Area
CAN_H and CAN_L wires
Healing Condition
1. Re-connection of the CAN_H (connector C1 pin no.2)
and CAN_L(connector C1 pin no.5) to ECU
2. Removal of above mentioned short circuit conditions
