Connector View & Information:-
Silver box side display connector
Display side connector
Inspection Method (If any):-
NO
B1C52-13: IC Display LVDS connector - circuit open
Overview:
ISO Code
B1C52-13
Customer Symptom
User is unable to see visual information on Instrument cluster
display. Instrument cluster display is not turning ON.
Fault Effects (On Vehicle)
No
Lamp Status (If Any)
No
Fault Detection Condition
4. User is unable to see visual information on
Instrument cluster Display.
5. This DTC gets logged when connection between
infotainment silver box and Instrument cluster
Display is Open.
6. Instrument cluster Display is not turning ON.
Normal Operating Condition
User is able to see visual feedback on Instrument cluster
Display
Probable Trouble Area
Wiring harness between silver box and Instrument
cluster Display.
Silver box connector and its connector terminals
TBA
TBA
