B1C20-13: Steering Wheel Control Input Signal - circuit open
Overview:
Write up for the Related Sensor/Actuator or system:-
Steering wheel control module – This steering wheel control module is located on steering wheel. Using steering
wheel control module, user can change volume/media/radio settings.
Pre-Check Points:
NO
Trouble Shooting:-
Below given flowcharts guides to troubleshoot the fault:
ISO Code
B1C20-13
Customer Symptom
User is unable to change volume/media/radio settings using
steering wheel control module.
Fault Effects (On Vehicle)
No
Lamp Status (If Any)
No
Fault Detection Condition
1. User is unable to change volume/media/radio settings
using steering wheel control module.
2. This DTC gets logged when connection between
steering wheel control signal input and silver box is
Open/Short to Battery.
Normal Operating Condition
When user changes settings of volume/media/radio using
steering wheel Control, accordingly infotainment system will
process it.
Probable Trouble Area
Wiring harness between silver box and Steering
wheel control.
silver box connector and connector terminals
Steering wheel control connector and its terminals
Intermittent connector and their terminals
Healing Condition
None
