Connector View & Information:-
Silver box Connector
Tweeter Connector
Inspection Method (If any):-
NO
B1C4F-13: Right Front Tweeter Assembly Output Power / Right Front Tweeter Assembly Input
Signal - circuit open
Overview:
Write up for the Related Sensor/Actuator or system:-
ISO Code
B1C4F-13
Customer Symptom
No audible audio output from front right tweeter.
Fault Effects (On Vehicle)
No audible audio output from front right tweeter.
Lamp Status (If Any)
No
Fault Detection Condition
3. No audible audio output from front right tweeter.
4. This DTC gets logged when connection between
front right tweeter and silver box is open.
Normal Operating Condition
When any media/radio source is played from infotainment
system, audio output is heard from car tweeter.
Probable Trouble Area
Wiring harness between silver box and tweeter
silver box connector and connector terminals
Tweeter connector and its terminals
Intermittent connector and their terminals
Healing Condition
None
TBA
TBA
