1.3. Terminologies
SR. Terminology Description
1
TML
TATA Motors Limited
2
EOL
End Of Line (diagnostics and testing)
3
KWP2000
Key Word Protocol 2000
4
ISO
International Organization for Standardization
5
MIL
Malfunction Indicator Lamp
6
MECU
Master ECU
7
VCI
Vehicle Communication Interface
8
OBD
On-Board Diagnostics
9
ECU
Electronic Control Unit
10 DTC
Diagnostic Trouble Code (Fault Code)
11 DLC
Data Link Control
12 J1962
Diagnostic Connector SAE reference standard
13 AFL
Active Front Lights
14 ASCII
American Standard Code for Information Interchange
15 IPC
Instrument Panel Cluster
16 CAN
Controller Area Network
17 COC
Center of Competence
18 DID
Data Identifier
19 E&E
Electrical and Electronics
20 BECU
Backup ECU
21 IGN
Ignition
22 LED
Light Emitting Diode
23 LIN
Local Interconnect Network
24 LSB
Least Significant Bit
25 ms
Millisecond
26 MSB
Most Significant Bit
27 NRC
Negative Response Code
28 OSI
Open Systems Interconnection
29 PBL
Primary Boot Loader
30 PBT
Primary Boot Tester
31 CDF
Configuration Data File
32 RAM
Random Access Memory
33 CI
Configuration Item
44 CM
Configuration Message
41 SBL
Secondary Boot Loader
42 SBT
Secondary Boot Tester
43 SWDL
SoftWare DownLoad
44 TBD
To Be Decided
46 TS
TATA Motors Standard
