27 / 71
298A W/L 0.35 (MU)
CAB
579A L/P 0.50 (MU)
CAB
591 BR/Y 0.50 (ALL)
EMS
595 O/B 0.75 (ALL)
EMS
596 Y/B 0.75 (ALL)
EMS
16D B/W 0.50 (AR)
CAB
681 L/O 0.50 (NK)
FRT
189 W/L 0.50 (NK)
FRT
682 Y/B 0.50 (NK)
FRT
213 BR/Y 0.50 (ALL)
EMS
689 GY/W 0.50 (ALL)
EMS
690 B/L 0.50 (ALL)
EMS
592 O/G 0.50 (ALL)
EMS
699 W/V 0.75 (ALL)
EMS
599 V/W 0.75 (ALL)
EMS
600 GY/BR 0.50 (ALL)
EMS
601 G/B 0.50 (ALL)
EMS
674 R/V 0.75 (ALL)
EMS
677 B/W 0.50 (ALL)
EMS
679 R/B 0.50 (ALL)
EMS
680 R/Y 0.50 (ALL)
EMS
676 R/W 0.50 (ALL)
EMS
57J L/R 1.00 (ALL)
EMS
57H L/R 1.00 (ALL)
EMS
57L L/R 1.00 (ALL)
EMS
57G R/Y 0.75 (ALL)
EMS
108L GY/R 0.35 (GN)
CAB
710 GY/B 0.35 (KF)
CAB
204G GY/L 0.50 (ALL)
CAB
640A B/W 2.50 (AR)
FRT
635 W/P 0.50 (AR)
CAB
710A GY/B 0.35 (HR)
CAB
738A GY/BR 0.35 (KF)
CAB
425 Y/B 0.50 (MU)
CAB
108A GY/R 0.50 (JD)
CAB
414L BR 0.35 (ALL)
CAB
47D GY 0.50 (ALL)
CAB
735 W/Y 0.50 (GN)
FRT
108G GY/R 0.50 (MU)
CAB
739 W/B 0.50 (GN)
FRT
365 W/L 0.50 (HA)
FRT
672 L/O 0.50 (HA)
FRT
108K GY/R 0.35 (GN)
CAB
108E GY/R 0.35 (GN)
CAB
204Q GY/L 0.50 (MU)
CAB
740 W/Y 0.35 (GN)
CAB
741 W/B 0.35 (GN)
CAB
47P GY 0.35 (ALL)
CAB
298 W/L 0.35 (MU)
CAB
717 W/L 0.35 (JD)
CAB
579 L/P 0.35 (MU)
CAB
666 L/P 0.35 (JD)
CAB
298B W/L 0.35 (MU)
CAB
584 W/L 0.35 (HA)
LKD
587 L/P 0.35 (HA)
LKD
579B L/P 0.35 (MU)
LKD
929 B/W 2.50 (AR)
CAB
108 GY/R 0.75 (ALL)
CAB
742 BR 0.35 (GN)
CAB
738 GY/BR 0.35 (HR)
CAB
366 BR 0.35 (HA)
CAB
582 GY/R 0.50 (HA)
LKD
581 BR 0.35 (HA)
LKD
29D Y/B 0.50 (AR)
CAB
98C BR 0.35 (ALL)
CAB
414L BR 0.35 (ALL)
CAB
29A Y/B 4.00 (ALL)
CAB
29 Y/B 4.00 (ALL)
CAB
PEPS
AND ACTUATOR
VGT POSITION SENSOR
EMS ECU
FUEL METERING UNIT
NR
08.10.18
24.08.18
12.06.18
11.06.18
C
14PP028135
14PP028120
14PP028093
14PP028073
B
A
SOP RELEASE
BETA II RELEASE
PP RELEASE
PO RELEASE
Q501/Q502
RP 30.09
TS 30.09
PR IW TS
PR IW TS
PR IW TS
PR IW TS
PHASE
DESIGN
DR4
ECOA
4
EMS
5412 5400 0007
26
70
A3
WB025
Sheet 24
WB026
Sheet 24
WB002
Sheet 26
0.03 Amps
STARTER FEEDBACK
5.0 Amps
AND ACTUATOR
SWIRL POSITION SENSOR
DIFFERENTIAL PRESSURE SENSOR(BS-IV)
PARTICLE FILTER,
COOLER BYPASS
HP-EGR
WB015
Sheet 24
LAMBDA SENSOR
CLUTCH SENSOR
PASSENGER COMP FUSE BOX
C001PF C001PM 25
C001PF C001PM 26
C001UM C001UF 9
C001UM C001UF 23
C001UM C001UF 26
C001UM C001UF 30
DIODE ASSY.
1.00 Amps
1.00 Amps
FASCIA SW
ECO MODE SW
SPORT MODE SW
0.03 Amps
PARKING ILLUMINATION
0.03 Amps
C001UM C001UF 56
for more details
Refer sheet 16
{
IGNITION RELAY
20.0 Amps
IGN SUPPLY
10.0 Amps
C001PM C001PF 24
BODY CONTROL MODULE
C001PM C001PF 22
WB002
Sheet 26
EA22
EA12
WB029
Sheet 27
WB022
Sheet 27
WB027
Sheet 27
WB028
Sheet 27
EA14
WB024
Sheet 24
C726C-18
Crank_Relay_Feedback
C017A-3
VGT Actuator +
C579-1
C579-2
C310A-1
C310A-2
C726C-17
Crank_Relay_Output
C017A-25
VGT Actuator -
C017A-7
Fuel metering unit Xply
C017A-6
Fuel metering unit
C726B-3
ClutchSwSig 90%
C726B-1
ClutchSwSig 10%
C292C-4
C579-5
C579-4
C579-3
C709A-1
Supply
C709A-3
Sig
C709A-2
Gnd
C292C-2
-
C292C-1
s
C292C-5
+
CZZZ-1
-
CZZZ-2
s
S57L
C574-5
v-
C574-1
v+
C574-3
-
C574-4
+
C574-6
C574-2
S579
C380A-2
C380A-1
C380A-10
C380A-6
C380A-5
C017K-42
DiffPressSensor Supply
C017K-16
DiffPressSensor Sig
C017K-15
DiffPressSensor Gnd
C017A-69
HP EGR Cooler Bypass
C017A-39
VGT Pos Sensor 5V
C017A-76
VGT Pos Sensor Gnd
C017A-77
VGT Pos Sensor Sig
C017A-28
swirl sig ground
C017A-5
Variable swirl actuator
C017A-29
swirl diagnostic feedback
C017K-52
Top Travel I/P- 10%
C017K-12
Extended Travel I/P-90%
C017K-34
ECO MODE SW
C017K-51
SPORT MODE SW
C017A-46
Lambda Sensor Heating1
C017A-104
Lambda Sensor Current Pump
C017A-105
Lambda Sensor Current Adjust
C017A-83
Lambda Sensor, Virtual Ground
C017A-84
Lambda Sensor Voltage nernst
S47
S204G
C462A-1
C462A-2
C183C-2
90%
C183C-3
10%
C462A-3
S298
C380A-3
C380A-7
C380A-9
C380A-12
C380A-4
S108
C115P-D3
C115P-D1
C115X-26
C115X-3
C021B-6
C021B-18
BatterySaverCntrl1
C183C-4
C183C-1
C115P-D5
C115P-D2
C115X-25
C115X-4
S29
