24 / 71
105A BR/L 0.50 (ALL)
FRT
105B BR/L 2.50 (ALL)
FRT
359 R 35.00 225 (ALL)
ALT
427 G/W 0.50 (HQ)
CAB
427A G/W 0.50 (HR)
CAB
105 BR/L 2.50 (ALL)
FRT
208 G/W 0.50 (ALL)
EMS
208 G/W 0.50 (NK) FRT
50 B 8.00 225 (ALL)
CCB
53D B 35.00 350 (NK)
TRN
53 B 35.00 260 (NK)
BNE
148 BR/L 2.50 (ALL)
EMS
92 R 35.00 (NK)
BPO
IC SEGMENTED
IC TFT
Motor
Starter
UNDERBONNET F/B
EMS ECU
PO RELEASE
A
14PP028093
12.06.18
NR
14PP028073
11.06.18
BETA II RELEASE
PR IW TS
PR IW TS
STARTING & CHARGING SYSTEM
HM 06.11
RP 06.11
TS 06.11
STOA
5412 5400 0007
23
70
DR4
C
B
14PP028135
14PP028120
08.10.18
24.08.18
SOP RELEASE
PP RELEASE
PHASE
DESIGN
PR SK TS
PR IW TS
{
for more details
Refer sheet no.16
HR
HQ
NK
ALL
OPTION
IC-TFT
IC-SEGMENTED
FCA DIESEL BS-IV
ALL VARIANTS
DESCRIPTON
3
Q501/Q502
OPTION CODE TABLE
C001UF C001UM 11
C001XF C001XM 5
ALTERNATOR
Block
11.2 Volts
BATTERY
TRANSMISSION
ON
EA28A
ON BIW
EA29
ON CCB
EA30
ON BIW
EA31
ON BIW
EA13A
STARTER MOTOR
Solenoid
Starter
BFT
C001XF C001XM 6
Block
STARTER
PF1
200.0 Amps
C026A-18
Battery charge sig
C026C-18
Battery charge sig
C017K-85
starter V-sensing i/p
C117A-G8
StarterinhibitRelay
S105
C080B-2
Charge Warn Lamp
C080A-1
C118C-1
C079A-1
C118A-1
C079B-1
C079G-1
C079C-1
