26 / 71
550A B/Y 0.50 (ALL)
CAB
25 P 0.50 (ALL)
CAB
692 L/B 0.75 (ALL)
EMS
687 L 0.50 (ALL)
EMS
688 V/R 0.50 (ALL)
EMS
702 GY/B 0.75 (ALL)
EMS
703 W/Y 0.75 (ALL)
EMS
704 BR/B 1.50 (ALL)
EMS
705 GY/B 1.50 (ALL)
EMS
715 L/R 1.50 (ALL)
EMS
585 R/B 1.50 (ALL)
EMS
586 R/Y 1.50 (ALL)
EMS
686 L/W 0.50 (ALL)
EMS
642 L 1.50 (ALL)
EMS
42 GY/R 1.50 (ALL)
EMS
644 BR/W 1.50 (ALL)
EMS
645 GY/R 0.75 (ALL)
EMS
394 P 0.50 (ALL)
LKD
526 B/Y 0.50 (ALL)
LKD
25G P 0.50 (ALL)
CAB
25L P 0.50 (ALL)
CAB
658 GY/L 0.50 (ALL)
EMS
90B BR 2.50 (ALL)
FRT
743 GY/G 0.50 (GF)
CAB
746 L/G 0.50 (GF)
CAB
650 W/G 0.50 (ALL)
EMS
651 W/R 0.50 (ALL)
EMS
652 W/O 0.50 (ALL)
EMS
653 BR/V 0.50 (ALL)
EMS
90C BR 2.50 (ALL)
FRT
374 BR 2.50 (ALL)
FRT
594 L/R 0.50 (ALL)
EMS
362 P 0.50 (ALL)
FRT
550 B/Y 0.50 (ALL)
FRT
745 GY/G 0.50 (GF)
FRT
749 L/G 0.50 (GF)
FRT
589 G/W 0.50 (ALL)
EMS
590 G/Y 0.50 (ALL)
EMS
593 GY/G 0.50 (ALL)
EMS
370 GY/G 0.50 (NM)
FRT
371 L/G 0.50 (NM)
FRT
716 B/V 0.50 (ALL)
EMS
646 Y 0.50 (ALL)
EMS
647 R/G 0.50 (ALL)
EMS
648 V/B 0.50 (NK)
FRT
711 BR/B 0.50 (NK)
FRT
649 L/P 0.50 (NK)
FRT
654 W/V 0.50 (ALL)
FRT
655 W/O 0.50 (ALL)
FRT
657 V/O 0.50 (ALL)
FRT
57F R/Y 0.75 (NK)
FRT
216B BR 0.50 (ALL)
FRT
95B Y/B 0.50 (ALL)
FRT
CRANK SHAFT SENSOR
NR
08.10.18
24.08.18
12.06.18
11.06.18
14PP028093
14PP028073
14PP028135
14PP028120
SOP RELEASE
BETA II RELEASE
A
C
B
PO RELEASE
PP RELEASE
EGR POSITION SENSOR & ACTUATOR
BODY CONTROL MODULE
BRAKE LAMP SWITCH
(EXTERIOR LIGHTING)
for more details.
Refer Sheet No. 42
C001QM C001QF 1
C001QM C001QF 10
INJECTOR 1
INJECTOR 2
INJECTOR 3
INJECTOR 4
EMS
FUEL FILTER
HFM SENSOR
RAIL PRESS SENSOR
EXHAUST GAS TEMP. SENSOR T3
SENSOR
COOLANT TEMP.
Q501/Q502
EMS ECU
HM 30.09
RP 30.09
TS 30.09
PR IW TS
PR IW TS
PR IW TS
PR IW TS
PHASE
DESIGN
DR4
ECOA
4
C001UF C001UM 16
C001UF C001UM 4
C001UM C001UF 41
C001UM C001UF 42
5412 5400 0007
25
70
A3
CRUISE SW
4700
R11002
SENSOR(FOR 90HP ONLY)
BOOST PRESSURE
CLOCKSPRING
CANCEL
510
R8002
SET RESUME
2200
R10002
1000
R9002
OIL PRESS S/W
WB017
Sheet 24
WB014
Sheet 24
EA3B
EA25A
EA3A
C047A-1
C300A-6
C021A-22
Brakelgtswsig
C180-1
C180-2
C180-4
C180-3
C047A-2
C300A-5
C300A-1
C300A-3
C300A-2
S25
C032A-2
C033A-1
C033A-2
C034A-2
C034A-1
C031A-1
C031A-2
C032A-1
C182A-4
C182A-3
C246A-10
-
C299A-1
+
C246A-8
+
C017A-99
Coolant temp sensor gnd
C307-2
C017A-100
Coolant temp sensor sig
C017A-20
Crankshaft speed sensor signal +
C307-1
C017K-76
IntakeAirTemp Sensor Sig
C017A-12
Exhaust gas temp sensor 3 Gnd
C017A-61
Boost temperature sensor signal
C017A-38
Boost pressure sensor 1 Supply
C017A-63
Rail pressure Gnd
C017A-62
Rail pressure ssr Signal
C017A-42
Rail pressure sensor Supply
C017A-13
Exhaust gas temp sensor 3 Sig
C017A-96
Boost pressure sensor 1 signal
C017K-45
FuelTemp sensor
C017A-95
Boost pressure sensor 1 gnd
C017K-9
Water In Fuel Sig
C017A-67
EGR MOTOR +
C017A-88
EGR MOTOR-
C017A-78
GND EGR Sensor
C017A-79
SIG EGR
C017A-40
5V_POS SENSOR EGR
C017A-21
Crankshaft speed sensor signal -
C017K-10
Main BrkSwitchSig
C017K-35
Redundant BrakeSw Sig
C017A-66
Injector 4 high side
C017A-45
Injector 3 low side
C017A-85
Injector 1 low side
C017A-43
Injector 2 low side
C017A-22
Injector 2 high side
C017A-24
Injector 3 high side
C017A-87
Injector 4 low side
C017A-64
Injector 1 high side
C017K-33
CRUISE GND
C017K-63
C017K-66
C017K-29
CRUISE I/P
C000-1
C000-2
C017K-86
HFM Sensor Sig
C017K-87
HFM Gnd
C017A-50
OIL PR SW
C017K-4
GND 2
C017K-65
FuelTempGnd
C017K-2
GND 1
C017K-6
GND 3
C246A-9
WIF Sen Sig
C299A-4
t
C299A-2
GND
C299A-3
-
C293A-1
-
C293A-2
s
C293A-3
+
C246A-6
C246A-5
C292A-4
S
C292A-3
+
C292A-1
-
C292A-2
t
C141-1
