605 / 948
BODY
47
2.26 REAR SEAT BELT
REMOVAL
1. Remove parcel shelf.
2. Remove rear seat backrest (for removal
process refer rear seat removal process).
3. Flip the cushion assembly.
4. Remove rear seat belt bottom mounting
fastener.
5. Remove the bottom mounting fastener & C
pillar upper and lower trim. (For procedure
refer C pillar removal process.)
6. Remove two upper mounting bolts on C piller
BIW panel.
7. Loosen and remove the RPLL mounting bolt.
8. Remove centre seat belt mounting bolts shown
in figure.
9. Remove the rear seat belt assembly.
FITMENT
For fitment follow reverse procedure of removal.
