SUSPENSION
33
21. REAR SUSPENSION DISMANTLING OR
INSTALLATION PROCESS
1. Position the vehicle in the two post lift.
2. Remove and loosen wheel nuts.
3. Remove the wheel.
4. Lift the vehicle using two post lift.
5. Slacken off the hand brake cable.
6. Remove csk screw M10x20 as shown
7. Remove the brake drum by gently tapping by
mallet.
8. Detach the hand brake cable from the lever on
the trailing shoe by moving the lever towards
the centre of the brake and removing the cable
nipple from its location in the end of the lever.
9. Remove Clip for Parking brake cable holding.
10.Insert a screwdriver through the hole in drum
and press against the hand brake lever.
