BODY
8
9.4.8 REMOVAL OF REAR SCUFF PLATE:
1. First remove 'B' pillar from lower and then
remove door beading at Trim.
2. Fold the Rear Seat to Remove Rear Screws
of rear scuff plate.
3. Remove rear Quarter Trim lower Screws and
upper two trim clips
4. Remove Rear Quarter Trim.
5. Remove rear scuff plate front Screw.
REFITMENT OF REAR SCUFF PLATE:
1. Fold Rear Seat to Refit Screws of rear scuff
plate.
2. Refit Front and Rear Screws of rear scuff
plate.
3. Refit Rear scuff plate door Beading.
