Revotron 1.2T
100
iii. Removal of Oil Sump
1. Rotate the engine at 180
0
for removal of oil
sump.
2. Remove the Oil Sump along with the Gasket.
3. Remove the Lube Oil Strainer and Gasket.
iv. Removal of Sensors
1. Remove Cam Phase Angle Sensor.
2. Remove Crank Angle/RPM Sensor from the
Engine Block.
3. Remove Coolant Temperature Sensor.
