AIR CONDITIONING
55
B OAT (Outside Ambient Temperature)
The ambient temperature sensor is an encapsulated thermistor that provides the ECU with an input of
external air temperature. Ambient sensor is a thermistor that decreases its resistance when temperature
increases and increases when temperature decreases.
Location
Outside Ambient Temperature (OAT) sensor located under the front grill / front bumper.
Inspection:
Measure the resistance between terminals of the sensor at minimum two temperatures. The resistance value
should match with stated values of resistance in table below
T (˚c)
R Gerber (Ω)
T (˚c)
R Gerber (Ω)
-30
53046.9±1326.1
+5
7594±113.9
-20
29092.1±610.9
+10
5953.9±101.2
-10
16567.3±281.6
+20
3737.3±78.4
-5
12662.1± 177.2
+30
2412±57.8
0
9773.2± 117.2
