571 / 1232
Automated Manual Transmission
43
3. Unscrew the connector and disconnect the
pipe from electric pump to hydraulic unit,
hydraulic unit side.
1. Loosen the screw and remove the cover
for the gear selection actuator.
1. Rotate the gear selection actuator anti-
clockwise by 90°.
1. Loosen the front screws fixing the hydrau-
lic unit to the gearbox.
1. Remove the hydraulic unit.
Remove the sealant from the gearbox and
the hydraulic unit.
