ELECTRICAL
37
REMOVAL & REFITMENT OF TAILLAMP &
BULBS
REMOVAL
1. Open Tailgate & ensure all lamps in OFF
condition.
2. Disconnect Tail lamp Connector.
4. Remove the two nut mounting fastener.
5. Pull the lamp at catcher points to release from
BIW & take lamp out from vehicle.
5. Rotate the turn signal bulb holder in anti-clock
wise direction to unlock the bulb holder from
lamp.
6. Remove the bulb holder from lamp.
6. Remove/replace the bulb.
