1.2L REVOTRON ENGINE
34
Piston, Crankshaft and Components
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Top Ring (3 Qty)
2 Taper Faced Ring (3 Qty)
3 Oil Ring (3 Qty)
4 Piston Pin (3 Qty)
5 Round Wire Circlip (6 Qty)
6 Connecting Rod (3 Qty)
7 Bearing Half (Connecting Rod)
8
Bolt (Connecting Rod) (M8 X 1) (6 Qty)
•
2.2 + 0.5
90° ± 5°
9 Woodruff Key
10 Crank Sensor Target Wheel
11 Assembly Vibration Damper Pulley
12 Washer (Damper Pulley)
13
Hex. Bolt M16x1
•
14.5 + 3.0
90° ± 5°
14
CSK SOC Screw M6X20 for crank sensor
wheel (3 Qty)
1.7 + 0.3
15
Bearing Shell Half Lower (Crankshaft) (4
Qty)
16
Bearing Shell Half Upper (Crankshaft) (4
Qty)
17 Thrust Washer (2 Qty)
18 Crankshaft
19 Flywheel
20
Hex. Bolt For Flywheel (M10 X 1.5) (6
Qty)
•
3.5 + 0.5
25° ± 5°
