1.2L REVOTRON ENGINE
31
Lubrication Pump and Components
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Oil pump cover
2 Hex Flange Bolt M8x55 (6 Qty)
2.5
3 Hex Flange Bolt M8x30 (2 Qty)
2.5
4 Oil Seal (Crank Shaft Front)
5 Oil Pump Assy.
6 Hex Flange Bolt M6x28 (13 Qty)
1.0
7 Stud CM6x18 (2 Qty)
8 O-Ring 25.00x3.55
9 Oil Pump Strainer
10 Flanged Clinch Nut M6 (2 Qty)
1.0
11 Gasket, TC To Oil Return Tube
12 Hex Flange Screw M6x18 (2 Qty)
1.0
13 Gasket, Piston Cooling Nozzle (3 Qty)
14 Nozzle Assy, Piston Cooling (3 Qty)
15 Cap Screw M5x10 (3 Qty)
0.8
16 Tube Assy, Turbocharger Oil Return
17 Gasket, TC Oil Return
18 Hex Flange Screw M6x18 (2 Qty)
1.0
19 Oil Sump
20 Hex Flange Screw M6x14 (18 Qty)
1.0
21 Sealing Washer (Oil Sump Drain Plug)
22 Magnetic Drain Plug
3.5
23 Hex Flange Bolt M8x50 (3 Qty)
2.5
24 Stiffener Bracket, Powertrain
25 Hex Flange Bolt M8x75
2.5
26 Pipe Union Bolt (2 Qty)
2.0
