77 / 1265
1.2L REVOTRON ENGINE
39
Turbocharger, Catcon and Components
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Hex Flange Nut Am8 (4 Qty)
2.0 + 0.3
2 Stud CM8x25 (4 Qty)
3 Stud BM6x18 (2 Qty)
4 Hose, EVRV Vent To Air Filter
5 Hex Flange Screw M8x18
2.0
6 Assy. Vacuum Modulator (BS-IV)
7 Hex Nut M6 (2 Qty)
1.0
8 Hose, EVRV To Turbocharger
9 Bracket Assy, EVRV Mtg On Cyl Head -
10 Clamp (Vacuum Hose)
11 Hose Assy, EVRV To NRV
12 Bracket - NRV Mounting
13 Hex Flange Screw M6x10
14
One Way Check Valve (NRV For Vacuum
Accumulator & EVRV Circuit)
15 Hose (Vacuum Line T Connector To NRV)
16 Hex Flange Screw M6x12
2.0
17 Hex Flange Screw M6x18
2.0
18 Pipe, Turbocharger Support
19 Heat Shield Assy, Turbocharger
20 Gasket, Turbocharger Intake
21 Turbocharger Assy
22 Gasket, Turbocharger Outlet
23 Oxygen Sensor (Lambda Sensor) (2 Qty)
5.0 ± 1.0
24 Hex Flange Screw M8x10
1.0
25 Hex Flange Screw M6x10
1.0
26 Heat Shield Assy, Turbocharger & Catcon
