TURNING NOISE REPAIR (1.5CRAIL)
2
E. Loose the mounting bolt of B-mount to
transmission.
F. Push the powertrain from A-mount side
towards B-mount with the help of rod placing
between A mount & Arm (The distance ‘d’
should be in between 23 - 25.3mm).
G. Tighten the mounting bolt of B-mount with 108
Nm torque.
H. Maintain the gap of
2 mm
both RH & LH side
stopper bracket with sub-frame.
I. Tighten the nut of both RH and LH side
stopper bracket with 40 – 45 Nm torque.
J. Fit the battery tray, battery in tray & connect
the battery teminal.
NOTE
Ensure that the distance ‘d’ is be in between 23 -
25.3mm.s
