DRIVESHAFT
9
C. CV JOINT OUTER DISASSEMBLY:
1. Clean the shaft thoroughly using cleaning
solvent and hold the shaft at the middle of the
axle shaft in the vice.
2. Remove the large seal retaining clamp from
the CV joint with a side cutter or a screw-
driver with rounded tip and discard.
FITMENT
For fitment, follow reverse procedure of removal.
