1.5L REVOTORQ ENGINE
146
vii. REMOVAL OF TIMING BELT
1. Insert the flywheel locking pin to lock the
flywheel.
SPECIAL TOOL
Flywheel Locking Pin.-: 2868 5890
0604
2. Remove the vibration damper pulley.
3. Loosen and remove the front timing cover
bolts and take out the cover.
4. Remove the bottom front timing cover.
5. Remove both the lifting hooks.
