1.5L REVOTORQ ENGINE
105
C. EXHAUST SYSTEM
ON VEHICLE REPAIRS
A. EXHAUST ASSY. REAR (MAIN SILENCER)
REMOVAL
1. Remove all the three supporting rubber
hangers on the rear side.
2. Loose and remove the connecting clamp bolt
from Main Silencer and also remove the
rubber hanger
3. Remove the main silencer assembly.
FITMENT
For fitment follow the reverse procedure of
removal.
B. EXHAUST PIPE ASSY. WITH PRE-
SILENCER
REMOVAL
1. Remove the mounting nuts of the
intermediate exhaust pipe connecting to the
front end pipe and Catcon.
2. Remove the rubber hangers and take out the
intermediate pipe.
FITMENT
For fitment follow reverse procedure of removal.
NOTE
Use new gaskets every time while fitment
and tighten nuts and bolts to specified
torque.
