1.5L REVOTORQ ENGINE
55
INSPECTION
1. Hold the air filter element up to a light
source. Light should be visible through the
element. There should be no holes or tears
in the element.
2. The filter can also be cleaned using low
pressure compressed air.
3. Replace the filter element if torn or light is
not visible through the filter.
INSTALLATION
1. Place the air filter element.
2. For re-assembling the cover, please ensure
that all the hinge lugs are properly assembled
in the slot of the air filter housing body, before
tightening the screws.
iv. FUEL FILTER REPLACEMENT
WARNING
If diesel leakage is detected, do not start
the vehicle or allow an open flame or spark
near the vehicle. Have the fuel leak
repaired immediately.
The fuel system is under pressure. Relieve
fuel system pressure before replacing the
filter.
DESCRIPTION
The fuel filter is mounted on transaxle on the front
side in the vehicle. A band clamp secures the fuel
filter in place. Replace the fuel filter as per
service schedule. When the vehicle is operated in
adverse conditions or where fuel quality is
questionable, more frequent replacement may be
necessary.
REMOVAL
1. Relieve fuel system pressure by removing the
power supply to the system fuel pump and
cranking the engine.
2. Disconnect the negative (-) battery cable.
3. Remove the fuel line connections (Quick fit
Connectors) to the fuel filter.
