1.2L REVOTRON ENGINE
111
3. Take out the main silencer assembly.
FITMENT
For fitment follow the reverse procedure of
removal.
FRONT PIPE ASSY. WITH PRE-SILENCER
REMOVAL
1. Disconnect the exhaust front pipe loosen the
clamp near Catcon and remove the bolt on the
engine.
2. Remove the rubber hanger from front end of
pre silencer and other one is from rear end.
3. Take out the Pre silencer assembly.
FITMENT
For fitment follow reverse procedure of removal.
CLOSED CATALYTIC CONVERTER
REMOVAL
1. Remove all the electrical connections.
2. Remove both the lambda sensor.
3. Disconnect the exhaust front pipe by loosening
the clamp bolts.
4. Remove the top mounting bolts of the exhaust
heat shield.
