NEXON

ELECTRICAL

213

1.29.1 BATTERY MOUNTED FUSE BOX (

BDU

)

CIRCUIT DIAGRAM

FUSE DETAIL

FUSE NO.

FUNCTION

FUSE RATING

PF1

STARTER

MOTOR

CAL1

WARNING

If Fuse box cover is removed for any reason, it

should be refitted properly at its original position.

1.29.2 ENGINE FUSE AND RELAY BOX

NOTE

The fuse box layout is for reference purpose only.

Please refer the sticker provided inside the fuse

box cover.
