ELECTRICAL

111

1.23 TAILGATE HANDLE SWITCH

REMOVAL& INSTALLATION

1. Disconnect the battery.

2. Remove the Tailgate Handle.

(Refer Tailgate

Handle Removal Procedure in the Body

Section).

3. Diconnect the electrical connection to the

tailgate switch.

4. Remove the clip on the handle.

5. Unscrew the tailagate handle cover with

dedicated screw panel.

6. Remove the door handle switch with wire

harness.

REFITMENT

For refitment follow the procedure in reverse.

NOTE

1. Ensure that door handle switch connector is

fitted tightly and properly.

2. After replacing the door handle switch, check

vehicle locking/ unlocking state changes by

pressing the replaced door handle switch.

3. The smart key shall be present during door

handle switch press.

4. Connect the Diagnostics tool and clear the

DTCs.
