NEXON

63 / 1133

1.2L REVOTRON ENGINE
25
 Cylinder Head-A
No. DESCRIPTION
NO REUSESEALANT
LUBRICATION
TORQUE(Kgf.m)
1 Cap Assy.,Intermediate Bearing
2 Camshaft Assy. With Pin Exhaust (TC)
3 Check Valve (2 Qty.)
4 Hollow Dowel (4 Qty.)
5 Cap Assy.,Intermediate Bearing
6 Gasket, Vacuum Pump
7 Assy. Vacuum Pump
8 Hex Flange Screw M6x20 (3 Qty.)
9 Camshaft Assy. With Pin, Intake (TC)
10 Hollow Dowel (2 Qty.)
11 Hex Flange Bolt M6x1x60 (4 Qty.) 1.5 ± 0.15
12 Cap, Intermediate Bearing, Rear
13 Plug MC 8x1
14 Hex. Bolt (Camshaft Brg. Cap) (6 Qty.) 1.5 ± 0.15
15 Hex Flange Bolt M6x35 (6 Qty.) 1.5 ± 0.15
16 Camshaft Bearing Cap (Inner) (6 Qty.)
17 Hex Flange Bolt M6x1x60 (4 Qty.) 1.5 ± 0.15
