1.2L REVOTRON ENGINE
23
Cylinder Head Cover
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1
Cover Assy,Cylinder Head
2
Ignition Coil (3 Qty.)
3
Hex Flange Bolt M6x25 (3 Qty.)
1.0 ± 0.2
4
Hex Flange Screw M6x22 (12 Qty.)
1.0
5
Hex Flange Bolt M6x40 (2 Qty.)
1.0
6
Solenoid Valve (2 Qty.)
7
Hex Flange Nut AM6 (2 Qty.)
•
1.0
8
Stud (2 Qty.)
•
1.0
9
Dipstick Assy.
Note:-
•
This Symbol indicates critical tightening torque.
