NEXON

59 / 1133

1.2L REVOTRON ENGINE
21
 Intake Manifold
No. DESCRIPTION
NO REUSESEALANT
LUBRICATION
TORQUE(Kgf.m)
1 Intake Manifold Support Bracket 1.0
2 Hex Flange Screw M6x14 (4 Qty.)
3 Hex Flange Nut Am6 (4 Qty.) 1.0
4 Stud CM6x45 (4 Qty.) 1.0
5 Electronic Throttle Body
6 Intake Manifold Assy.
7 Stud CM8x30 (4 Qty.) 2.5
8 Hex Flange Nut M8 (4 Qty.) 2.0 + 0.3
9 Hex Flange Screw M6x18
10 Pressure/Temperature Sensor (Map Sensor)
11 Hex Flange Screw M6x14
12 Hex Flange Screw M8x18
13 Bracket Assy., Intake Manifold (Plenum Side)
