SUSPENSION
39
10. REAR BRAKE DRUM BEARING FITMENT
Insert the new bearing to the brake drum using
the bearing installer special tool part no (2871
5890 4202) as shown in the Figure.
10a fit the circlip
11. Detach the hand brake cable from the lever
on the trailing shoe by moving the lever
towards the centre of the brake and removing
the cable nipple from its location in the end of
the lever as shown in Figure.
12.Remove the hand brake cable holder lock pin
from the back plate
13.Remove the rear sensor cable mountings on
the twist beam axle
14.Disconnect the brake lines mounting on the
twist beam as shown in Fig.
15.Disconnect the bundy pipe/Hose from wheel
cylinder. Remove bleed screw. Put rubber dust
cap on to the bundy pipe to avoid brake fluid
from spilling and contamination.
