NEXON

1.5L REVOTORQ ENGINE

E. AIR MASS FLOW SENSOR

This sensor is mounted between air filter and

turbocharger. It gives Information about the amount

of air quantity & temperature entering the engine.

This input is used by the ECU for corrections of fuel

quantity based on amount of air availability for

optimization of exhaust gas circulation & the

turbocharger control. While assembling, the AMF

sensor the point of the arrow should be towards the

Turbo charger.
