1.2L REVOTRON ENGINE
116
6. Loosen and remove the fuel filler neck
assembly mounting fasteners.
7. Unscrew the fastener at filler neck support
bracket.
8. Remove the fuel filler and breather hose
clamps from filler neck end.
9. Take out fuel filler assembly along with
breather from body shell.
INSPECTION
Check if dust has blocked the 2 way cap, change
cap if found defective.
WARNING
A small amount of fuel may be released
after fuel lines are disconnected. To avoid
the chance of injury, cover the pipe to be
disconnected with cotton cloth. Do not use
cotton waste..
CAUTION
To avoid damage to vapour hoses while
disconnecting, slide back the clamps then
twist the lines as you pull.
FITMENT
Follow the reverse order of removal for fitment.
