1.2L REVOTRON ENGINE
112
5. Remove the bottom mounting bolts of the
exhaust heat shield and take it out.
6. Loosen and remove the bottom mounting bolts
of the CCC.
7. Loosen and remove the top mounting bolts of
the CCC and take it out.
FITMENT
For fitment follow the reverse procedure of
removal.
NOTE
Use new gaskets every time while fitment
and tighten nuts and bolts to specified
torque.
