1.2L REVOTRON ENGINE
107
3. Remove the Air filter mounting bolts in the
front.
4. Remove the air filter from grommet in upward
direction
and remove out from vehicle.
FITMENT
For fitment follow the reverse order of removal.
C
.
INJECTOR REMOVAL
1. Remove the air filter.
2. Disconnect the electrical connection to all the
fuel injectors.
3. Remove the fuel supply connection.
4. Remove the mounting bolts of the fuel rail and
remove out the rail along with injectors.
