ELECTRICAL
97
6. Remove the mounting fasteners and take out
the unit.
REFITMENT
For refitment follow the removal procedure in
reverse.
1.18.6 TWEETERS
Tweeter is a loudspeaker designed to produce
high frequencies.
LOCATION
There are total four tweeters. Each is fitted inside the
front door and rear door.
PINOUT DETAILS
PIN
DESCRIPTION
1
-ve
2
+ve
