ELECTRICAL
96
PIN
DESCRIPTION
AM/FM Antenna
1
AmFMSignal
2
AmFmShield
REMOVAL
LEVEL A
1. Remove glove box.
(Refer Body Section for
removal procedure)
.
2. Disconnect all the electrical connection to the
silver box.
3. Remove the mounting fasteners and take out
the unit.
LEVEL B
4. Remove glove box.
(Refer Body Section for
removal procedure)
.
5. Disconnect all the electrical connection to the
silver box.
