NEXON

1.5L REVOTORQ ENGINE

197

Signal/Output Voltage

The analog output signal is good between 0 and

NOTE

Check the AMF Sensor with no mass flow. The

above given values are for zero mass flow. Every

tiny whiff of air will cause a NTF".

CONNECTOR DETAILS

PINOUT DETAILS

Pin No

Description

NTC

Ubat

GND

Uref

v. VENTURI

It is an integral part of High pressure pump. It has

inlet & outlet connections. One connection comes

from injector back leak circuit & the other

connection goes to the fuel tank (return Line), in

between there is a "T" connector which goes to

the fuel filter.
