1.5L REVOTORQ ENGINE
149
18. Remove the front mounting bolt of the H.P.
pump.
19. Loosen and remove the mounting bolts and
take out the H.P. pump assembly.
20. Loosen and remove the mounting bolts and
take out the water pump assembly.
21. Remove the timing gear camshaft pulley.
22. Loosen and remove the mounting bolts and
take out the rear timing cover.
23. Remove the mounting bolt and take out the
crankshaft gear.
