1.2L REVOTRON ENGINE

167

VI. Fitment of cylinder head cover and

peripherals

1. Carefully place the rubber gasket.

2. Install the cylinder head cover. Fit mounting

bolts as per the specified toque and sequence

as below.

3. Install vacuum pump assembly.

4. Install EVRV unit along with its support

bracket.

5. Install the clutch cover assembly.

6. Install the oil filter holder.
