NEXON

1.2L REVOTRON ENGINE

117

FUEL TANK

REMOVAL

1. Place the vehicle in a 2 poster lift.

2. Disconnect the electrical connections of the in-

tank pump and the fuel lines.

(For Removal

Refer Tank Unit removal process).

3. Disconnect the fuel filler hose and the breather

hose.

4. Support the fuel tank from below.

5. Remove the four mounting bolts from tank and

lower the tank carefully.

INSPECTION



Check all hoses and pipes connected to fuel

tank

for

leaks,

loose

connections,

deterioration or damage. Replace if

necessary.



Check fuel pump and fuel level gauge

gaskets for leaks, cracks etc. Replace if

necessary.



Visually inspect fuel tank for leaks and

damage. Replace if necessary.



Check TPV for dust accumulation. Clean if

required.

FITMENT

Follow the reverse order of removal for fitment.
