9.2.30 “B” PILLAR TRIMS
REMOVAL
1. Remove both the front and rear door beading.
2. Loosen and remove the lower anchorage bolt
of seat belt.
3. Unlock B pillar lower trim from upper trim and
Pull out B pillar lower trim.
4. Remove front seat belt upper anchorage bolt.
5. Remove the web guide clip by rotating in the
anti-clockwise direction and taking it out from
the guide.
6. Pull out B Pillar upper trim.
7. Similarly follow the above mentioned steps for
the other side.
FITMENT
For fitment follow reverse procedure of removal.
