ELECTRICAL
60
COMBI STALK REPLACEMENT PROCEDURE
1. Remove the combi switch from vehicle. Refer
removal & refitment of steering nacelle from
steering section.
2. Disconnect combi switch connection.
3. Remove the two mounting screw of the stalks
as shown below
4. Remove the stalk.
INSTALLATION:
1. Fit the new stalk.
2. Tight the mounting screws of stalk.
3. Fit the combi switch.
INSTALLATION
1. Fit the new stalk
2. Tight the mounting screw of stalk
3. Fit the combi switch
Torque value Table
Component
Tightening torque
value
Light / Wiper Stalk
tightening torue in
Daesung make combi
Switch
0.3 to 0.4 Nm
Clock spring
6 to 8 kgf-cm
