DRIVETRAIN-TA65 Star
57
3. Now place the outer synchro cone.
4. Place the engaging gear in such a way that the
inner cone lugs sit properly inside the grooves
provided in the engaging gear.
5. Place the engaging gear 1st and 2
nd
such that
the reverse gear tooth over it is towards the 1st
gear.
6. Place the 2
nd
gear and assemble the twin
cones as shown and place it over the engaging
gear as shown in below figures.
